Product Details
Place of Origin: SHENZHEN CHIAN
Brand Name: SC
Certification: CCC, ISO14001, CE, IP65
Model Number: P3.91
Document: Product Brochure PDF
Payment & Shipping Terms
Minimum Order Quantity: Square Meters / 1 Piece
Price: Negotiable
Packaging Details: Wooden box,Flight Case
Delivery Time: 10 days after received deposit
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000 Square Meter/Square Meters per Month
|
Pixel Pitch:
|
3.91mm
|
CABINET Size:
|
500mm*500mm
|
Drive Mode:
|
16 Scan
|
Color:
|
1R1G1B
|
Brand Name:
|
SOL COLUR
|
Cabinet Materrial:
|
Aluminum
|
Module Number:
|
Rental LED Display P3.91
|
Place Of Orign:
|
Shenzhen, China
|
|
Pixel Pitch:
|
3.91mm
|
|
CABINET Size:
|
500mm*500mm
|
|
Drive Mode:
|
16 Scan
|
|
Color:
|
1R1G1B
|
|
Brand Name:
|
SOL COLUR
|
|
Cabinet Materrial:
|
Aluminum
|
|
Module Number:
|
Rental LED Display P3.91
|
|
Place Of Orign:
|
Shenzhen, China
|
Fanless design, excellent natural heat dissipation achieves zero noise, providing quiet working environment, best choice for indoor rental e
Produce Specification:
|
Unit Module |
Item | Parameter |
| Model Number | HX-P3.91-16S | |
| Module size | 250mm*250mm | |
| Pixel pitch | 3.91mm | |
| Pixels Density | 65536/m2 | |
| Pixel configuration | 1R1G1B | |
| Package mode | SMD1921 | |
| Pixel resolution | 64dots(W)*64 dots(H) | |
| Max Power | 38W | |
| Module weight | 0.7kg | |
| Drive type | Constant drive | |
| Scan mode | 1/16scan | |
| Port type | HUB75-A | |
| Brightness of white balance | ≥4800cd/m2 |
|
Cabinet |
Dimension | 500mm*500mm |
| Monomer Module Number | 4pas | |
| Power supply | 5V/40A*1pas | |
| Protection grade | IP65 | |
| Pixel per cabinet | 128mm*128mm | |
| Best viewing distance | 2M～18M | |
| Best viewing angle | 160°(W) 120°(H) | |
| Temperature |
storage:-35℃～+85℃ working:-20℃～+50℃ |
|
| Relative humidity | 10%-95% | |
| Thickness | 65m |
|
Power |
Working voltage | AC220V±10% |
| Average Power consumption | 320W/㎡ | |
| Max.Power consumption |
≤800W/㎡
|
|
| Current | ≤20mA(single LED) | |
|
Control system |
CPU | Pentium4 or above P4 |
| Operation system | WIN98/2000/NT/XP/WIN7 |
