Highlight:
                                                                                                                                                                                                                Lightweight P8 Outdoor Led Screen, Exterior Led Display Easy To Maintain, Lightweight  Exterior Led Display


Module Size:	320mm*160mm	Pixel Pitch:	8mm
Pixel Configuration:	1R1G1B	Max Power:	25W
Weight:	0.37kg

Module Size:	320mm*160mm
Pixel Pitch:	8mm
Pixel Configuration:	1R1G1B
Max Power:	25W
Weight:	0.37kg

Lightweight P8 Outdoor Led Screen Exterior Led Display Easy To Maintain

Pixel Pitch 8mm Outdoor Advertising LED Display Brightness 4800-5500 Easy To Maintain

Product Description

1. Nice appearance and simple structures.

2. Lightweight. Convenient in transporting and installing & saving labor cost, suitable for flow shows.

3. Humanized operating interface with breakdown indicator lights, easy to maintain.

4. High debugging brightness and no damage to gray scale, achieving the debugging technology for nice image.

P8 technology parameters

Unit Module	Item	Parameter
	Model Number	SF-SS8-4-A
	Module size	320mm*160mm
	Pixel pitch	8mm
	Pixels Density	15625dots/m2
	Pixel configuration	1R1G1B
	Package mode	SMD2727
	Pixel resolution	40dots(W)*20dots(H)
	Max Power	25W
	Module thickness	22mm
	Weight	0.37kg
	Drive type	Constant drive
	Scan mode	1/4
	Port type	HUB75-A
	Brightness of white balance	≥6200～6500cd/m2
LED Cabinet	Dimension	1024mm768mm100 mm
	Monomer Module Number	24pcs
	Power supply	5V/40A*4pcs
	Thermal discharge	fan 2pcs
	Pixel per cabinet	128mm*96mm
	Best viewing distance	8M～15M
	Best viewing angle	120°(W) 110°(H)
	Temperature	storage:-35℃～+85℃ working:-20℃～+50℃
	Relative humidity	10%-95%
	Thickness	122mm
Power	Working voltage	AC220V±10%
	Average Power consumption	330W/㎡
	Max Power consumption	≤1100W/㎡
	Current	≤20mA(single LED)
Control system	CPU	Pentium4 or above P4
	Operation system	WIN98/2000/NT/XP/WIN7
	Control method	Synchronization
Main technical parameter	Driving device	Constant drive IC
	Refresh frequency	≥1920HZ
	Grey scale/colors	4096gray level/16.7M colors
	MTBF	≥100000hours
	Power switch	Automatic switch
	Display Mode	≥800600/1024768
